Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole

Product Details

Place of Origin: People's republic of China

Brand Name: VISION

Certification: ISO9001:2008; Rohs, Reach, SGS

Model Number: Y30BH

Payment & Shipping Terms

Minimum Order Quantity: 1 PIECE

Price: Negotiable

Packaging Details: Standard packing for sea and air transportation( box carton with plastic sack or Composite board box) for ferrite mangets, or for customer request.

Payment Terms: negotiable

Supply Ability: 50000 Piece/Pieces per Day

Get Best Price
Highlight:

Ferrite Disc Magnets With Countersunk Hole

,

Y30BH Ferrite Disc Magnets

,

Anisotropic Ferrite Ring Magnet

Type:
Permanent
Composite:
Ferrite Magnet
Shape:
Disc
Application:
Industrial Magnet
Material:
Sro Or Bao And Fe2o3
Size:
Customers' Request
Magnetism Direction:
Thickness Or Customized
Tolerance:
+/- 2%
Processing:
Ceramic Processing Technology
Density:
4.8 - 4.9 G/cm3
Grade:
Y30BH
Properities:
Anisotropic
Port:
Shenzhen Or Customer' Request
Type:
Permanent
Composite:
Ferrite Magnet
Shape:
Disc
Application:
Industrial Magnet
Material:
Sro Or Bao And Fe2o3
Size:
Customers' Request
Magnetism Direction:
Thickness Or Customized
Tolerance:
+/- 2%
Processing:
Ceramic Processing Technology
Density:
4.8 - 4.9 G/cm3
Grade:
Y30BH
Properities:
Anisotropic
Port:
Shenzhen Or Customer' Request
Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole

Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole



Applications of Ferrite Magnets:

• Speaker magnets
• DC brushless motors
• Magnetic Resonance Imaging (MRI)
• Magnetos used on lawnmowers and outboard motors
• DC permanent magnet motors (used in cars)
• Separators (separate ferrous material from non-ferrous)
• Used in magnetic assemblies designed for lifting, holding, retrieving and separating
• Magnetic Door Catcher
• Instrument and Meters
• Toys
• Arts and crafts




Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole 0

Produce name

Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole

Shape Disc (ferrite magnet shape can customized)
Material Sro or Bao and Fe2o3
Coating No
Tolerance in size Length and Width: +/- 2%, Height: +/- 0.1
Magnetization direction Thickness, Length, axially, diameter, radially, multipolar
Grade

Y25, Y30, Y33, Y35

Process Sintered Ceramic processing technology
MOQ Samples could be offered
Delivery time 3 to 10 days for sample, 10 to 30 days for order. (According to the stock information)
Application Dc motors, Louderspeaks, Magnetic Separators, Automotive Sensors, Educations, etc
Certification ROHS, SGS, ISO9001
Characteristics Lost Cost,Higher Coercive Force; It need not to be coated because it is difficult to be eroded and oxidized
Payment T/T, western Union, Paypal, L/C


In order to quote the best price to you in timely, please kindly provide the following information when you send the inquiry:

  1. Material type and grade required
  2. Size and shape, if available, a sketch or drawing with dimensions and tolerances.
  3. Application of the magnets
  4. Max working temperature
  5. Quantity required
  6. Delivery with Magnetized or not? Magnetization direction?Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole 1

Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole 2



More Shapes:

Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole 3



Attributes of ferrite Magnets:
• Least expensive material compared to alnico and rare earth magnets
• High intrinsic coercive force
• Available in simple shapes only due to manufacturing process
• Lower service temperature than alnico, greater than rare earth
• Lower energy product than alnico and rare earth magnets



Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole 4

Established in 2008, located in Dongguan City, Dongguan Vision Plastics Magnetoelectricity Technology Co., Ltd. is a high-tech manufacturer for magnetic material, we mainly specialize in permanent neodymium magnet and ferrite magnet.

Our factory have 3000 square meters area, with first-class production equipment and perfect testing philosophy, that means we can provide top-quality products for our customers. Now we have export our magnet to Europe, North American, Southeast Asian and other countires.
For all, We persist in providing superior quality, competitive prices as well as prompt delivery. Based on this strong background for many years. We serve our customers sincerely while they treat us as their trustful friends.



 Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole 5

Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole 6



Custom Ferrite Disc Magnets Y30BH Grade D15.2Xd3.2Xd8XH6 With Countersunk Hole 7

Standard packing for sea and air transportation, box carton with plastic sack or composite board box to protect the magnets.

Or for customer request.
